Air+ PROJECT 250-17,000M3/H

Boasting energy savings of 20-50%, a highly compact structure, and stable year-round process temperatures, the Air+ PROJECT is an air chiller with nothing but pluses.

Compact Air Cooler

Air+ PROJECT is an innovative new air chiller system designed to provide cooling air to blown film and sheet extrusion lines. It comprises two main elements, the Air+ chiller (a stand-alone unit that produces cold air), and BRA+ cooling batteries. The latter are constructed within a closed framework for maximum insulation and superior bubble cooling performance on blown film lines.

Advantages Of The Air+ PROJECT 250-17,000m3/h

• Uniform process temperature throughout the year
• Min. air temperature 5°C
• HGBP cooling technology
• Control panel with operation diagnosis
• Air filter with large surface area
• Ergonomic and compact design
• Cooling capacity ranges between 13.5 and 93.8 kW
• Significant energy savings achieved when applied to blown film extrusion processes
• Supported by BRA+ batteries

How The Air+ Chiller Works

The Air+ chiller functions by using the condensing water from a condensing kit or chiller at 15-35°C to cool in a simple and direct way. As a result, significant energy savings of up to 50% can be achieved in comparison with other models. The Air+ chiller also features a control panel with operation diagnosis, an air filter with a large surface area, and an ergonomic and compact design that ensures plant space is maximised. There are seven models in the new AIR+ range offering maximum airflow rates from 1000 to 7000 m³/hr and cooling capacities from 13.5 to 93.8 kW.

BRA+ Batteries

The AIR+ PROJECT is supported by BRA+ batteries. BRA+ units feature a large surface area for maximum heat exchange, an integral diffuser for low air velocity and removable air filters for ease of maintenance. Other design features include a proportional three-way valve for precise temperature control, a thermometer that monitors ambient temperature and a collection tank with drain port for condensate. There are 13 models in the BRA+ range of batteries offering airflow rates between 250 and 17,000 m³/hr and cooling capacity between 2.4 and 169 kW.

Find Out More About The Air+ PROJECT Chiller

For more information on the Air+ PROJECT Chiller, please get in touch and speak to one of our highly trained engineers. We can either use plant specifications to assist you over the telephone or arrange to visit your site if your requirement is more complex. Remember, we also offer a free energy saving survey, so if you feel your plant could benefit from a thorough analysis, please get in touch.
